Utility Multi-Gas Leak Detector for Emergency Response
The GOLIATH Utility Multi-Gas Leak Detector is a rugged, explosion-proof gas detection instrument engineered for natural gas utilities, emergency response teams, pipeline operators, and industrial safety professionals. Designed for Leak Detection and Repair (LDAR), confined space entry, gas odor investigations, and pipeline inspections, it detects combustible gases, toxic gases, oxygen, and optional pressure and flow measurements in a single field-ready instrument.
Built with an integrated diaphragm pump and high-performance sensors, the GOLIATH delivers rapid detection of methane, propane, carbon dioxide, carbon monoxide, hydrogen sulfide, and oxygen. Optional pressure measurement up to 29 psi (2,000 hPa) and gas flow velocity measurement make it an ideal solution for gas utility maintenance, regulator stations, pipeline commissioning, and emergency leak response.
Ideal Applications
- Natural gas utility operations
- Emergency gas leak response
- Pipeline inspections
- Confined space entry
- Building gas inspections
- Gas pressure regulator stations
- LDAR (Leak Detection & Repair)
- Pipeline purging and commissioning
Key Features
- Detects methane, propane, oxygen, carbon monoxide, carbon dioxide, and hydrogen sulfide
- Integrated diaphragm sampling pump
- Optional pressure measurement up to 29 psi (2,000 hPa)
- Optional gas flow velocity measurement
- Optional ethane analysis
- Fast methane and CO₂ response
- Audible and visual alarms
- Stores over 1 million measurements
- Rugged ATEX-certified explosion-proof design
- IP54-rated enclosure
- Rechargeable NiMH battery
- Made in Germany
-
SKU: MBT-201050
Technical Specifications
| Specification | Value |
|---|---|
| Detectable Gases | Methane (CH₄), Propane (C₃H₈), CO₂, O₂, CO, H₂S |
| Methane | ppm, %LEL, %Vol. |
| Carbon Dioxide | 0–5% / 0–100% Vol. |
| Carbon Monoxide | 0–500 ppm |
| Hydrogen Sulfide | 0–100 ppm |
| Pressure (Optional) | 0–29 psi (0–2,000 hPa) |
| Display | 128 × 64 Backlit LCD |
| Battery | Rechargeable NiMH |
| Storage | 1,000,000+ measurements |
| Charging Time | Approx. 3 hours (charging cradle) |
| Protection Rating | IP54 |
| Operating Temperature | 14°F–104°F (-10°C to 40°C) |
| Dimensions | 7.9 × 3.9 × 3.4 in (200 × 100 × 87 mm) |
| Weight | 2.8 lb (1.25 kg) |
