USB Signal Generator | 50 MHz–22 GHz | MBT-SYN0020A-U

USB Signal Generator | 50 MHz–22 GHz | MBT-SYN0020A-U

Model: MBT-SYN0020A-U

Compact, USB-controlled RF signal generator covering 50 MHz to 22 GHz for microwave development, laboratory testing, and automated measurement systems.

50 MHz–22 GHz  •  1 Hz resolution  •  Up to +20 dBm output  •  USB-C and API control

Request a Quote Get pricing and lead time
$3,250.00 - $3,250.00
$3,250.00
$3,250.00 - $3,250.00
$3,250.00
Download Datasheet
View full specifications
↓

22 GHz USB RF Synthesizer

The MBT-SYN0020A-U is a compact, high-performance RF signal source for engineers, researchers, educators, and automated test environments. Covering 50 MHz to 22 GHz with 1 Hz frequency resolution, the synthesizer provides precise frequency and output-power control in a portable USB-powered package.

Use the included graphical user interface (GUI) to control the generator, or integrate it with your automated test system using the available API. Pulse modulation, frequency and power list modes, and an external reference clock input make it useful for RF development, production verification, and portable local oscillator (LO) applications.

Product Video

Technical Specifications

RF Performance

Frequency range
50 MHz to 22 GHz
Frequency resolution
1 Hz
Maximum output power
Up to +20 dBm (frequency dependent)
Minimum output power
−40 dBm
Power resolution
0.5 dB
Frequency stability
±1 ppm
Phase noise
Low-phase-noise architecture

Modulation & Operation

Pulse modulation
Internal and external
Pulse rise/fall time
30 ns
List mode
Frequency and power lists
Reference clock input
10–110 MHz
Operating temperature
0°C to 50°C

Connectivity & Hardware

Model
MBT-SYN0020A-U
RF connector
SMA female
Pulse input
SMA female
Reference input
SMA female
Control interface
USB 3.2 Gen 1 Type-C

Ideal Applications

  • Wireless infrastructure development
  • RF up-conversion and down-conversion
  • Automated test equipment (ATE)
  • Production verification
  • University and research laboratories
  • General RF testing
  • Portable local oscillator (LO) applications
