VCXO - Low Phase Noise
1.25MHz to 1,600MHz
CMOS and Differential Output Logic
Voltage controlled crystal oscillators (VCXOs) are found at the heart of base stations that target precision service and high data rates, and are an integral part of phase locked loops. We are committed to helping you find the VCXO with the exact specifications to meet your needs. We offer VCXOs with a range from 1.25MHz to 1,600MHz, with low phase noise, CMOS and differential output logic.
Key Specifications
- Outputs: CMOS, Sine, LVDS, LV-PECL (Differential)
- Frequency Range: 0.001 MHz to 1600 MHz
- Voltage Options: +1.8V, +2.5V, +3.3V, +5.0V
- Package Sizes: 2.5×2.0 mm to DIP (20.7×13.1 mm)
- Temp Range: -10°C to +70°C up to -55°C to +125°C
- Stability: ±50 ppm to ±10 ppm
- Pull Range: ±25 ppm to ±100 ppm
- Jitter (RMS): 0.009 ps to 0.6 ps
- Ultra-low jitter options
- PLL-based models for wide frequency range
- Differential outputs for low-noise designs
- Compact to through-hole packages
- Industrial temperature support
